IPCom v5 Receiver Overview¶

IPCom v5 is a receiver for collecting, processing, routing, and monitoring security system events. It provides a web interface for operations and administration.

The editions below are the same IPCom v5 product with different deployment models:

• Windows install
• Linux install (hardware or VM)
• RL25 hardware receiver

1. Deployment variants¶

2. Capability comparison by deployment¶

Functional differences between editions:

Relay via receiver means device events and statuses are forwarded to Protegus 2 through IPCom, and supported actions can be sent back through IPCom to devices.

3. Hardware requirements¶

Use these sizing baselines when planning new installations.

3.1 Linux install (hardware or VM)¶

Linux platform requirements:

• IPCom v5 Linux edition is supported on amd64 (x86_64) only.
• Recommended base OS is Debian Stable (amd64).
• Debian netinst links point to the current Stable release and can change over time.
• For controlled deployments, pin the exact Debian ISO filename/version in your rollout documentation.
• Non-amd64 platforms (for example arm64/aarch64) are not supported for IPCom v5 Linux deployment.
• If hardware is non-amd64, use a supported alternative such as Windows installation or RL25 hardware.

Notes:

• For database-heavy deployments, the 256 GB enterprise SSD recommendation is mainly for endurance (higher DWPD), not only raw capacity.
• Plan additional free disk space for logs, backups, and update rollback files.

3.2 Windows install¶

Minimum recommended specification:

• Windows 11 Pro or Windows 11 Enterprise
• 2-core CPU
• 8 GB RAM
• 128 GB HDD/SSD (SSD preferred)

3.3 RL25 hardware receiver¶

• RL25 ships with SSD and RAM preinstalled.
• Use RL25 when appliance-style deployment and prevalidated hardware are preferred.

4. Shared capabilities (all variants)¶

4.1 Core receiving and control¶

• IP receiver, SMS receiver (optional / GM14 / SMPP), and reception via RS232.
• Remote TRIKDIS configuration and remote TRIKDIS control.
• Supervision, message routing, and radio message filtering.
• Receiver management through Webpage (HTTP/HTTPS).

4.2 Protocols and integrations¶

• Supported protocols: Trikdis (TCP/UDP/COM/SMS).
• CMS/Automation protocols: Split / Multi-Port Reporting.
• CMS formats: Ademco 685, Monas3, Surgard MLR2, MLR2000, SIA DC-09.
• CMS/Automation transport types: TCP Client/Server, RS232, JSON, Webhook.
• SQL DB interface and object information export.

4.3 UI and operational features¶

• Editable user interface.
• Account override at receiver level and related account (panel) display.
• Ability to ignore primary messages.
• Device blocking by ID (planned).
• Settings change log.
• Receiver system overview dashboard.
• Remote update.
• Multi-level user list.

5. Operational scope¶

5.1 Access and security¶

• Browser login by IP address or domain with port selection.
• HTTP/HTTPS management interface, with SSL usage discussed for secure access.
• User list, administrator account, role assignment, and session/token controls.

For step-by-step access methods (Web and Windows .exe), see Access and login. For user creation, password, scopes, and token procedures, see Users tab.

Operational security baseline:

• Restrict management UI access by network allowlist or VPN.
• Use HTTPS with valid certificates for all admin sessions.
• Keep administrator reserved for break-glass use; use named least-privilege accounts for daily work.
• Rotate credentials and integration secrets on a regular schedule.

5.2 Monitoring and operations¶

• Dashboard view of system and object state.
• Online/offline/untracked tracking and event statistics.
• System logs and session logs for operational visibility.

5.3 Events, routing, and protocol handling¶

• Event list handling with filtering/search capabilities.
• Ping/heartbeat handling for connectivity supervision.
• Routing and output handling for CMS/automation flows.

5.4 Integration and data¶

• SQL-backed operational data and object export.
• API/integration support through JSON and webhook transport.

5.5 Deployment and lifecycle¶

• Deployment on Windows and Linux platforms.
• Configuration import/export and remote update workflows.
• Licensing and server-side operational considerations.

6. Quick access¶

Use these pages as primary entry points:

• Access methods and troubleshooting: Access and login
• Screen-by-screen operational behavior: Status tab (and the rest of User interface)
• User and permission procedures: Users tab
